The HLS project provides consistent land surface observations from both the Operational Land Imager (OLI) aboard the joint NASA/USGS Landsat 8 and Landsat 9 satellites and the Multi-Spectral Instrument (MSI) aboard Europe’s Copernicus Sentinel-2A, Sentinel-2B, and Sentinel-2C satellites. Due to the spectral similarities between the Landsat (L30) and the Sentinel-2 (S30) instruments, data harmonization between these sensors can generate higher-frequency imagery products for land surface monitoring and applications.
| HLS Band Code Name L30 | HLS Band Code Name S30 | OLI Band Number | MSI Band Number | Wavelength (micrometers) | Band |
|---|---|---|---|---|---|
| band01 | B01 | 1 | 1 | 0.43 – 0.45 | Coastal Aerosol |
| band02 | B02 | 2 | 2 | 0.45 – 0.51 | Blue |
| band03 | B03 | 3 | 3 | 0.53 – 0.59 | Green |
| band04 | B04 | 4 | 4 | 0.64 – 0.67 | Red |
| - | B05 | - | 5 | 0.69 – 0.71 | Red-Edge 1 |
| - | B06 | - | 6 | 0.73 – 0.75 | Red-Edge 2 |
| - | B07 | - | 7 | 0.77 – 0.79 | Red-Edge 3 |
| - | B08 | - | 8 | 0.78 – 0.88 | NIR Broad |
| band05 | B8A | 5 | 8A | 0.85 – 0.88 | NIR Narrow |
| band06 | B11 | 6 | 11 | 1.57 – 1.65 | SWIR 1 |
| band07 | B12 | 7 | 12 | 2.11 – 2.29 | SWIR 2 |
| - | B09 | - | 9 | 0.93 – 0.95 | Water Vapor |
| band09 | B10 | 9 | 10 | 1.36 – 1.38 | Cirrus |
| band10 | - | 10 | - | 10.60 – 11.19 | Thermal Infrared 1 |
| band11 | - | 11 | - | 11.50 – 12.51 | Thermal Infrared 2 |
