Worldview Image of the Week

Iceberg A68A Approaching South Georgia Island

Image captured on 3 December 2020, by the MODIS instrument, aboard the Terra satellite.



Iceberg A68A Approaching South Georgia Island on 3 December 2020 (Terra/MODIS)

Image of Iceberg A68A approaching South Georgia Island, in the southern Atlantic Ocean, acquired on 3 December 2020. The photo-like, true color corrected reflectance image was captured by the Moderate Resolution Imaging Spectroradiometer (MODIS), aboard NASA's Terra satellite. Iceberg A68A calved from the Larsen C Ice Shelf in July 2017. View the iceberg's movement over the past 3 years in Worldview.

Use the comparison tool to compare true color corrected reflectance imagery (on the left "A" side) with false color (Bands 3-6-7) corrected reflectance imagery (on the right "B" side) to see how the iceberg to the south and the snow on the island to the north are easily distinguished in red. The Bands 3-6-7 combination is useful for mapping snow and ice. Snow and ice are very reflective in the visible part of the spectrum (Band 3), and very absorbent in Bands 6 and 7 (short-wave infrared, or SWIR). Since the only visible light used in these images (Band 3) is assigned to red, snow and ice appear bright red. The more ice, the stronger the absorption in the SWIR bands, and the more red the color. Thick ice and snow appear vivid red (or red-orange), while small ice crystals in high-level clouds will appear reddish-orange or peach.

Visit Worldview to visualize near real-time imagery from NASA's EOSDIS, and check out more Worldview weekly images in our archive.
