Fires and Burn Scars on the Border of Bolivia and Brazil

Image captured on 4 October 2020, by the MODIS instrument, aboard the Terra satellite.

Fires on the border of Brazil and Bolivia on 4 October 2020 (MODIS/Terra)

Image of fires and burn scars on the border of Bolivia and Brazil, acquired on 4 October 2020 by the Moderate Resolution Imaging Spectroradiometer (MODIS) instrument, aboard NASA's Terra satellite. This false color image is comprised of MODIS bands 7-2-1. This band combination is useful for highlighting burned areas (shown here in deep red).

Burned areas or fire-affected areas are characterized by deposits of charcoal and ash, removal of vegetation and/or the alteration of vegetation structure. When bare soil becomes exposed, the brightness in Band 1 may increase, but that may be offset by the presence of black carbon residue; the near infrared (Band 2) will become darker, and Band 7 becomes more reflective. When assigned to red in the image, Band 7 will show burn scars as deep or bright red, depending on the type of vegetation burned, the amount of residue, or the completeness of the burn.

View a comparison of imagery from 4 July 2020 and 4 October 2020. Note the red burned areas/burn scars in the October image.

Visit Worldview to visualize near real-time imagery from NASA's EOSDIS, and check out more Worldview weekly images in our archive.
