The map above shows a false-color corrected reflectance image of the Pipeline Fire north of Flagstaff, Arizona, on June 13, 2022. The fire was first reported at 10:15 a.m., MST, by a fire lookout on June 12, 2022. This image was acquired by the Moderate Resolution Imaging Spectroradiometer (MODIS), aboard NASA's Terra satellite. The false-color image is a false-color Red-Green-Blue (RGB) composite where Red is Band 7, Green is Band 2, and Blue is Band 1. This band combination is most useful for distinguishing burn scars from naturally low vegetation or bare soil and enhancing floods. Vegetation appears green, water is black/dark blue, burn scars are red, and the actively burning fire front is bright red.
Click on the image to open the full version of Worldview in a new browser tab.
Visit Worldview to visualize near real-time imagery from NASA's EOSDIS; check out more Worldview weekly images in our archive.
Sources: Pipeline Fire, InciWeb - Incident Information System
